Autotek Alloy Series - 4 Channel 1100 Watts Car Amplifier - AYA-1100.4

AutotekSKU: AUTAYA11004

Price:
$ 98.99
 More payment options

Description

Overview

Be cool and stay cool with the Autotek Alloy Series 1,100 Watt 4 Channel Class AB Amp! Featuring a compact design while staying cool, the Alloy Series delivers unrivaled clarity to subwoofers and speakers. Included with built-in electronic crossovers and high-level inputs, Autotek Alloy models easily tie into OEM (factory) audio systems that do not offer RCA output as well as ones that do. Easy, under-seat self-installation will have you enjoying Alloy levels of clarity in no time. This Alloy 4 channel amp can be used 4 channel stereo, dual stereo bridged, stereo + bridged mono, and dual bridged mono modes.

Features

  • 1,100 watts max
  • 40 watts x 4 at 2 ohms
  • 30 watts x 4 at 4 ohms
  • 60 watts x 2 at 4 ohms mono bridged
  • Operation modes: 4-channel stereo, dual stereo bridged, stereo + bridged mono, and dual bridged mono
  • Frequency response: 10 Hz to 22 kHz
  • Bass boost 0/+6/+12 dB
  • Built-in electronic crossovers
  • Variable electronic 12 dB per octave
  • .2 to 9 volt variable voltage
  • Maximum low voltage signal from the source unit comes into the amplifier through a low voltage circuit which delivers minimal distortion through the amplification process
  • Pro-Fi High Speed MOSFET components maximize power efficiency while improving sound quality and minimizing distortion
  • Quick Thermal Dispersion Technology assures additional mass in the aluminum heat sink keeps the amplifier running cool with nearly undetectable distortions during normal music listening
  • High-energy PWM (Pulse Width Modulated) power supply delivers power with minimal impact on the electrical system
  • RCA inputs provide the highest sound quality connection; quality RCA materials helps prevent interference and minimize distortion in the signal path
  • High-level inputs easily tie into OEM audio systems that do not offer RCA output to maximize aftermarket amplifier power
  • Nickel-plated brass connection with terminals allow for secure connection while resisting corrosion
  • Screw down connectors
  • 4 gauge 12-volt/ground power terminal
  • Accepts 12 gauge speaker wire
  • 30 amp fusing
  • Includes window sticker

Specifications

  • Audio Input Type: RCA Pair (2)
  • Fuse Type: 30A
  • Mount Type: Surface Mount
  • RMS Output: 2x60W @ 4ohm, 4x30W @ 4ohm, 4x40W @ 2ohm
  • Bass Knob Included Yes/No: Yes
  • Voltage Rating (Master): 9 VOLT
  • Peak Power Rating: 1100.0000 WATT
  • Amplifier Class: AB
  • Primary Color: Silver
  • Manufacturer Color: Silver
  • Product Height: 2.4000 INCH
  • Product Length: 10.2250 INCH
  • Product Weight: 3.9500 POUND
  • Product Width: 6.4000 INCH
  • Color: Silver
